Xenbase Image ID: 44879

Figure 2. Stromelysin-3 (ST3) and collagenase-4 (Col4) have distinct spatiotemporal expression profiles during embryogenesis. Whole-mount in situ localization of ST3 (A,C) and Col4 (B,D) mRNA showed very restricted expression patterns during development at stages 32 (A,B) and 45 (C,D). ST3 was largely restricted to the branchial arches (A, single arrow) and dorsal posterior endoderm (A, double arrow) at stage 32 and to structures in the thorax (C, t) and the dorsal anterior axis (C, d) at stage 45. Col4 could not be detected at stage 32 (B) and was only detectable at approximately stage 45 where it was also present in the thorax (D, t) and the dorsal anterior axis (D, d), although in a somewhat different pattern compared with ST3. Image published in: Damjanovski S et al. (2001) Copyright © 2001. Image reproduced with permission of the Publisher, John Wiley & Sons. Gene Synonyms Species Stage(s) Tissue mmp11.L gene 14, matrix metalloproteinase-11, st-3, st3, stromelysin 3, stromelysin-3 X. laevis Throughout NF stage 32 branchial arch rectal diverticulum pharyngeal arch head endoderm mmp1.S col4, collagenase-4, MMP-18, mmp18, xcol4 X. laevis Throughout NF stage 32 mmp11.L gene 14, matrix metalloproteinase-11, st-3, st3, stromelysin 3, stromelysin-3 X. laevis Throughout NF stage 45 eye endoderm notochord cloaca head endoderm mmp1.S col4, collagenase-4, MMP-18, mmp18, xcol4 X. laevis Throughout NF stage 45 notochord foregut eye pharyngeal arch head endoderm Image source: Published Larger Image Printer Friendly View
