???displayArticle.abstract???
Multiciliate cells employ hundreds of motile cilia to produce fluid flow, which they nucleate and extend by first assembling hundreds of centrioles. In most cells, entry into the cell cycle allows centrioles to undergo a single round of duplication, but in differentiating multiciliate cells, massive centriole assembly occurs in G0 by a process initiated by a small coiled-coil protein, Multicilin. Here we show that Multicilin acts by forming a ternary complex with E2f4 or E2f5 and Dp1 that binds and activates most of the genes required for centriole biogenesis, while other cell cycle genes remain off. This complex also promotes the deuterosome pathway of centriole biogenesis by activating the expression of deup1 but not its paralog, cep63. Finally, we show that this complex is disabled by mutations in human Multicilin that cause a severe congenital mucociliary clearance disorder due to reduced generation of multiple cilia. By coopting the E2f regulation of cell cycle genes, Multicilin drives massive centriole assembly in epithelial progenitors in a manner required for multiciliate cell differentiation.
???displayArticle.pubmedLink???
24934224
???displayArticle.pmcLink???PMC4083089 ???displayArticle.link???Genes Dev ???displayArticle.grants???[+]
Figure 1. Multicilin interactions with E2f family members and Gmnn. (A,B) Extracts of stage 12 animal caps were prepared from Xenopus embryos that were injected with the indicated RNAs and subjected to Western analysis with the indicated antibody before (input) and after immunoprecipitation (IP). (C–E) The domain structures of Multicilin (C), Dp1 (D), and E2f4 (E) are diagrammed along with deletion mutants that were tested for their ability to form the EDM complex, summarizing data shown in Supplemental Figure 2.
Figure 2. MCC differentiation is blocked in the skin of E2f4δCT-expressing embryos. (A–C) Shown are confocal images of embryonic skin (stage 28) of control embryos (A) or embryos injected with RNA encoding E2f4 (B) or E2f4δCT (C). Embryos were also injected with RNA encoding mRFP (red) and Hyls1-GFP (green) to mark membranes and basal bodies/centrioles, respectively, and stained for cilia (blue). Cells extending one or two cilia are marked with an arrow in C. Different cell types are identified based on morphology and cilia staining as outer cells (OCs), MCCs, small intercalated cells (INCs), and ciliated cells (CCs). Bar, 10 μm. (D) Representation of different skin cell types in control or E2f4- or E2f4δCT-expressing embryos based on 12 fields (98 μm2) from six embryos. (E) Effects on the cell cycle can be indirectly read out by the size of outer cells (Stubbs et al. 2012). E2f4δCT significantly (P < 0.05) decreases average cell size based on 24 cells from six embryos, indicating that it weakly promotes cell division. (F) Basal body number in MCCs in control or E2f4- or E2f4δCT-expressing embryos. Basal body counts based on 10 to 15 MCCs taken from six embryos. In all graphs, error bars indicate SD, and values significantly different (P < 0.05) from controls based on a two-tailed t-test are marked (asterisks).
Figure 3. E2f4δCT and Gmnn block Multicilin-induced basal body assembly during MCC differentiation. (A–D) Shown are confocal images of the embryonic skin expressing Multicilin-HGR alone (A) or with E2f4 (B), E2f4δCT (C), or Gmnn (D). Multicilin-HGR activity was induced with DEX at stage 12 and embryos fixed at stage 28. Membranes are marked with mRFP (red), basal bodies with Hyls1-GFP (green), and cilia in blue. Arrows denote monociliated cells. Bar, 10 μm. (E) Basal body number induced by ectopic expression of Multicilin-HGR activity in the presence of E2f4 and E2f4δCT. (F) Basal body number or the number of ciliated cells per field induced by Multicilin-HGR alone or in the presence of Gmnn. Basal body counts based on 10 to 15 cells taken from six embryos. Error bars indicate SD, and values significantly different (P < 0.05) from controls based on a two-tailed t-test are marked (asterisks)
Figure 4. E2f4δCT inhibits centriole gene expression during MCC differentiation. (A) RNA-seq analysis of skin progenitors isolated from Xenopus embryos expressing Multicilin-HGR alone or with E2f4δCT. Skin progenitors were isolated at stage 10, treated with DEX at stage 11 to induce MCC differentiation, and then extracted for RNA 9 h later. GO terms (P < 0.01) for genes down-regulated by E2f4δCT with the highest significance for microtubule (MT)-associated structures, including centrioles. GO term analysis for genes up-regulated by E2f4δCT failed to find a significant term. (B) Tukey box plot showing fold changes in response to E2f4δCT in the background of Multicilin-HGR-induced differentiation for both centriole components based on the supplemented list generated by Azimzadeh et al. (2012) or for cell cycle genes (Kegg Pathway) (Supplemental Tables 2, 3) (C) Heat map showing log2 fold change in response to E2f4δCT in Multicilin-HGR samples. (D) RNA samples were generated as in A but then analyzed in triplicate for the expression of the indicated gene using quantitative RT–PCR. RNA levels are shown after normalization to ubiquitously expressed ornithine decarboxylase (odc) RNA and are set relative to a value of 1 for uninjected controls. Fold change in the presence and absence of E2f4δCT is indicated.
Figure 6. Mutations that cause human RGMC affect EDM complex formation and function. (A) Extracts of skin progenitors (stage 12) isolated from embryos injected with the indicated RNAs were subjected to Western blot analysis prior to (input) or after immunoprecipitation (IP) using the indicated antibodies. (B–E) Shown are confocal images of the skin in embryos expressing Multicilin-R370H and/or E2f4δCT-VP16 as indicated. Membranes are marked with mRFP (red), basal bodies are marked with Chibby-GFP (green), and cilia are labeled in blue. (F) The percentage of MCCs in the skin for each RNA injection. Values that differ significantly from the control based on a two-tailed t-test are marked ([*] P < 0.01). (G–K) Shown are confocal images of the skin in embryos expressing activated Notch (ICD) alone or with Multicilin-R370H and/or E2f4δCT-VP16 as indicated. Membranes are marked with mRFP (red), basal bodies are marked with Chibby-GFP (green), and cilia are labeled in blue. (L) The percentage of cells that are MCCs in the skin for each RNA injection. Values for Multicilin- and Multicilin-R370H/E2f4δCT-VP16-expressing embryos are not significantly different. Data were obtained from 10 fields from five embryos. Error bars indicate SD. Bars, 10 μm.
Azimzadeh,
Centrosome loss in the evolution of planarians.
2012, Pubmed
Azimzadeh,
Centrosome loss in the evolution of planarians.
2012,
Pubmed
Balestra,
Multiciliogenesis: multicilin directs transcriptional activation of centriole formation.
2014,
Pubmed
,
Xenbase
Bettencourt-Dias,
SAK/PLK4 is required for centriole duplication and flagella development.
2005,
Pubmed
Blythe,
Chromatin immunoprecipitation in early Xenopus laevis embryos.
2009,
Pubmed
,
Xenbase
Boon,
MCIDAS mutations result in a mucociliary clearance disorder with reduced generation of multiple motile cilia.
2014,
Pubmed
,
Xenbase
Carroll,
Evo-devo and an expanding evolutionary synthesis: a genetic theory of morphological evolution.
2008,
Pubmed
Chen,
CP110, a cell cycle-dependent CDK substrate, regulates centrosome duplication in human cells.
2002,
Pubmed
Chung,
Coordinated genomic control of ciliogenesis and cell movement by RFX2.
2014,
Pubmed
,
Xenbase
Cizmecioglu,
Cep152 acts as a scaffold for recruitment of Plk4 and CPAP to the centrosome.
2010,
Pubmed
Danielian,
E2f4 is required for normal development of the airway epithelium.
2007,
Pubmed
Deblandre,
A two-step mechanism generates the spacing pattern of the ciliated cells in the skin of Xenopus embryos.
1999,
Pubmed
,
Xenbase
Dobin,
STAR: ultrafast universal RNA-seq aligner.
2013,
Pubmed
Dzhindzhev,
Asterless is a scaffold for the onset of centriole assembly.
2010,
Pubmed
Firat-Karalar,
Proximity interactions among centrosome components identify regulators of centriole duplication.
2014,
Pubmed
Fischer,
Polo-like kinase 4 transcription is activated via CRE and NRF1 elements, repressed by DREAM through CDE/CHR sites and deregulated by HPV E7 protein.
2014,
Pubmed
Fliegauf,
When cilia go bad: cilia defects and ciliopathies.
2007,
Pubmed
Habedanck,
The Polo kinase Plk4 functions in centriole duplication.
2005,
Pubmed
Hatch,
Cep152 interacts with Plk4 and is required for centriole duplication.
2010,
Pubmed
,
Xenbase
Heinz,
Simple combinations of lineage-determining transcription factors prime cis-regulatory elements required for macrophage and B cell identities.
2010,
Pubmed
Hoh,
Transcriptional program of ciliated epithelial cells reveals new cilium and centrosome components and links to human disease.
2012,
Pubmed
Kanehisa,
KEGG: kyoto encyclopedia of genes and genomes.
2000,
Pubmed
Kanehisa,
Data, information, knowledge and principle: back to metabolism in KEGG.
2014,
Pubmed
Kent,
BLAT--the BLAST-like alignment tool.
2002,
Pubmed
Langmead,
Fast gapped-read alignment with Bowtie 2.
2012,
Pubmed
Lee,
Wide-ranging functions of E2F4 in transcriptional activation and repression revealed by genome-wide analysis.
2011,
Pubmed
Lin,
Global changes in the nuclear positioning of genes and intra- and interdomain genomic interactions that orchestrate B cell fate.
2012,
Pubmed
Marcet,
Control of vertebrate multiciliogenesis by miR-449 through direct repression of the Delta/Notch pathway.
2011,
Pubmed
,
Xenbase
McGarry,
Geminin, an inhibitor of DNA replication, is degraded during mitosis.
1998,
Pubmed
,
Xenbase
Pefani,
Idas, a novel phylogenetically conserved geminin-related protein, binds to geminin and is required for cell cycle progression.
2011,
Pubmed
Quigley,
Specification of ion transport cells in the Xenopus larval skin.
2011,
Pubmed
,
Xenbase
Roberts,
RNA-Seq and find: entering the RNA deep field.
2011,
Pubmed
Sadasivam,
The DREAM complex: master coordinator of cell cycle-dependent gene expression.
2013,
Pubmed
Sorokin,
Reconstructions of centriole formation and ciliogenesis in mammalian lungs.
1968,
Pubmed
Stamatoyannopoulos,
An encyclopedia of mouse DNA elements (Mouse ENCODE).
2012,
Pubmed
Stubbs,
The forkhead protein Foxj1 specifies node-like cilia in Xenopus and zebrafish embryos.
2008,
Pubmed
,
Xenbase
Stubbs,
Multicilin promotes centriole assembly and ciliogenesis during multiciliate cell differentiation.
2012,
Pubmed
,
Xenbase
Tang,
Centriole biogenesis in multiciliated cells.
2013,
Pubmed
Tang,
The human microcephaly protein STIL interacts with CPAP and is required for procentriole formation.
2011,
Pubmed
Thorvaldsdóttir,
Integrative Genomics Viewer (IGV): high-performance genomics data visualization and exploration.
2013,
Pubmed
Trimarchi,
Sibling rivalry in the E2F family.
2002,
Pubmed
Wallmeier,
Mutations in CCNO result in congenital mucociliary clearance disorder with reduced generation of multiple motile cilia.
2014,
Pubmed
,
Xenbase
Yu,
Foxj1 transcription factors are master regulators of the motile ciliogenic program.
2008,
Pubmed
Zhao,
The Cep63 paralogue Deup1 enables massive de novo centriole biogenesis for vertebrate multiciliogenesis.
2013,
Pubmed
,
Xenbase
